Amplifier ITC T-120MA
ITC T-120MA is a desktop mini amplifier with a built-in mixer. It can be used to play background music or alerts in retail spaces, warehouses, restaurants and cafes, educational and public institutions, as well as in exhibition halls and other small spaces. The amplifier can work with broadcast speakers at 100 V, as well as with low-impedance speakers at 4-16 Ohms. The output power of the device is 120 W. On the front of the device there is a main output volume control, next to which there are three LED indicators of operation status. Next are three input volume controls: Mic 1, Mic 2/Aux, Aux 2. The mixer is also equipped with a two-band equalizer to correct the sound of the system. To control the equalizer, two bass and treble level controls are available. On the back of the amplifier there is an output for connecting to speakers on clamp terminals. Next to it is a switch for the type of output power: 100 V or for low-impedance speaker systems at 4-16 Ohms. Next is a 2 x RCA stereo output, to which you can connect, for example, other amplifiers. Next are the stereo inputs Aux 1 and Aux 2 on 4 x RCA connectors. To connect two dynamic microphones, 2 x 1/4" Jack TRS inputs are available. Using a separate switch, you can select the type of input signal - from the Aux 1 or Mic 2 input. TC T-120MA has a switching built-in power supply, as well as an energy-saving digital class D amplifier. It is also equipped with protection against short circuit, overheating and overload. The device operates in a frequency range from 80 Hz to 16 kHz, and its weight is 2.4 kilograms.
- Amplifier type: Class D
- Output power: 120 W (4-16 ohms, 100 V)
- Frequency range: 80 Hz - 16 kHz
- Inputs: 4 x RCA (aux), 2 x 1/4" Jack TRS (mic)
- Outputs: Screw terminal, 2 x RCA
- Input sensitivity: +5 mV (mic), 360 mV (aux)
- Equalizer: ±10 dB 100 Hz (LF), ±10 dB 10 kHz (HF)
- Signal to noise ratio: 75 dB
- Protection: overheat, short circuit and overload
- Consumption: 180 W
- Dimensions: 284 x 196 x 66 mm
- Weight: 2.4 kg
