Exell EDM16D Digital Mixing Console
Exell EDM16D is a digital mixing console that has 16 inputs/8 outputs.
Price on request
- Number of channels: 16
- Number of microphone and line inputs: 16
- Mic Input Connectors: XLR, TRS 6.3mm
- Microphone input type: balanced
- Frequency response of microphone inputs: 20 Hz – 20 kHz (+/- 0.5 dB)
- Mic input gain range: 0 – 70 dB
- Microphone input THD: 0.01%
- Mic input impedance: 3 kOhm
- Phantom power: +48V
- Signal to noise ratio: -105 dB
- Phase: Normal/Reverse
- Delay: 0 to 200 ms
- Equalizer: Frequencies: 20 Hz-20kHz -20dB/+ 12dB Q= from 0.404 to 28.852 4-band equalizer (HF, VHF, LF, LF);
- Squelch: Threshold = -120 dB to -20 dB
- Compressor: Threshold = -24 dB to +24 dB Attack: 3 - 100 ms Release Time: 2x,4x,6x,8x,16x,32x Ratio: 1.0 to 128
- Number of output channels: 8 assignable XLR outputs; L/R +4 mono buses + 4 stereo buses
- Type of output channels: Balanced
- THD: 0.005%(20 Hz – 20 kHz)
- Frequency response: 20 Hz – 20 kHz (+/- 0.5 dB)
- Output level max: +18 dBu
- Output impedance: ＜100Ω
- Headphone output jack: 6.3mm TRS jack
- Headphone Output Impedance: ＜50Ω
- Output level max for headphones: +18 dBu
- Digital input/output: DANTE;Bluetooth;USB;AES/EBU - (optional)
- USB format: 3.0
- REC format: wav
- Crosstalk: -80 dB
- AD/DA converter: Up to 24 bit/192 kHz
- DSP: 40-bit floating point processor
- FX Modules: Reverb x1, Echo x2, Graphic Equalizer (GEQ) x2
- Screen resolution: Touch screen 10.1’’; 1280x800
- Faders: 9 motorized faders, 100mm
- Network: Wi-Fi; external module
- System: Android
- Power consumption: 50 W
- Operating voltage: 90 – 240 V, 50 – 60 Hz
- Dimensions (WxHxD): 408 x 122 x 515 mm
- Weight: 6.8 kg
