LED screen LG LSCB018
The ultra-thin and lightweight LG LSCB018 LED screen with a thickness of 35 mm can be installed and used in any type of room without restrictions. The LSCB series of LED screens can be easily installed and serviced from the front for easy operation. Thanks to this feature, no additional space is required to service the back of the screen. Its LED modules can also be simply attached or detached using a magnetic tool. Each cabinet features a 16:9 aspect ratio, which is most commonly used in displays for presenting FHD and UHD content. This allows you to continue to use your existing content without the added cost and time of editing. LG LSCB series LED screen has been certified as fireproof and prevents the rapid spread of flames. You will have enough time to deal with an emergency if a fire does occur.
- Type: LED cabinet assembly
- Cabinet resolution, pixels: 320 x 180
- Pixel pitch, mm: 1.88
- LED type: 3 in 1 SMD
- Static contrast: 5000:1
- Pixel density per m2: 284444
- Brightness, nit: 800
- Module resolution, pixels: 160 x 90
- Viewing Angle: H:160°,V:160°
- Color temperature (default), K: 6500
- LED working life, h: 100000
- Refresh rate, Hz: 3840
- Operating temperature: -10° to 45°C
- Energy consumption (Max), W/m2: 890
- Energy consumption (Max), W/Unit: 150
- Protection class, IP: IP30 / IP30
- Construction material: Aluminum
- Service: Frontal
- Platform: LCIN006 controller
- Features: Ultra-thin, 90° corner design, fire protection certified, LCIN006 controller
- Installation type: Indoor
- Module height, mm: 168.75
- Module length, mm: 300
- Module weight, kg: 0.4
- Cabinet length, mm: 600
- Cabinet width, mm: 337.5
- Cabinet depth, mm: 35
- Cabinet weight, kg/unit: 5.2
