Resource set "VIDERETREK 1" Robotrack
It is a resource for children's educational robotics kits "Robotrek". The “Videretrack 1” resource set allows you to expand the capabilities of the Trackduino controller by adding a microcomputer with a special operating system. This set with a connected HD video camera will help solve problems related to: Object recognition - FACE; Tracking guide lines; Detection of graphic primitives (circles); Recognition of QR codes; Searching for movement; Analysis of the color scheme of the frame. The set will allow you to make interesting projects and participate in various competitions based on computer vision. Video camera specifications Sensor: OV9712 Matrix size: 1/4 inch Maximum resolution: 1280x720 Image format: YUV2 (YUYV), MJPEG Frame rate: 1280x720 @ 30fps USB protocol: USB2.0 HS / FS OTG protocol support: USB2.0 OTG Automatic exposure control AEC: yes Automatic white balance AEB: yes AGC support: yes Adjustable parameters: brightness, contrast, color saturation, hue, sharpness, gamma Supported resolutions: 160x120, 176x144, 320x240, 352x288, 640x480, 800x600, 960x720, 1280x720 Operating voltage: 5V DC Operating current: 120mA ~ 220mA Focal length: 12 mm Field of view: 17 degrees (depending on the lens up to 144 degrees) Operating temperature: -20 to +70 deg.C Installation size: 38x38 mm (compatible with 32x32 mm) Supported systems: WinXP / Vista / Win7 / Win8 / Linux (above Linux-2.6.26) / MAC-OS X 10.4.8 or later / Android 4.0 or higher Weight 82 g. Dimensions 50x50x25 mm. Microcomputer Specifications Processor: 64-bit quad-core ARM Cortex-A53 with a clock frequency of 1.4 GHz on a Broadcom BCM2837 single-chip RAM: 1GB LPDDR2 SDRAM digital video output: HDMI composite output: 3.5 mm (4 pin) USB ports: 4× USB 2.0 wireless network: WiFi 2.4/5 GHz, 802.11n Ethernet: 10/100/1000 MB RJ45 For this equipment there is an educational and methodological complex “Fundamentals of Computer Vision”, which is sold separately.
- Contents: Adapter board Raspberry pi3 SD card 8 Gb memory with operating system Case parts Vitrek Jumper closed Power button long HD video camera with 720 p resolution in the case Disk with software and instructions.
- Age: From 12 years
- Material: Plastic, metal
- Storage: Box
- Country of origin: Russia
