Digital Signage

Professional panel LG 55VH7J-H

The LG 55VH7J-H's super-thin 1.74mm bezel seam between display bezels dramatically reduces the impact of bezels on the viewing experience and provides an immersive and seamless video wall experience for the viewer. The panel has a built-in tool that allows you to eliminate optical distortion due to the display bezel. Objects at the junction of two displays are compensated for by the thickness of the seam, providing a seam-free experience. A special algorithm allows for synchronization of display scans to eliminate the effect of dynamic image shift at the junction of video panels. Large format screens are usually located above the audience level. In this case, the requirements for image uniformity increase significantly. The viewing angle of the 55VH7J-H display is sufficient to display content at an angle of up to 40˚ without any optical distortion. The IPS matrix technologically provides better management of liquid crystals, which gives better viewing angles. It attracts attention with clear, vibrant colors regardless of the viewer's position. The menu section structure is optimized for commercial use. Similar parameters are grouped and adapted for use in the graphical interface, reducing the time spent searching and setting the necessary parameters. Traditional GUI displays were designed for landscape orientation, so the OSD was not adapted for portrait orientation. The OSD display has a mode adapted for portrait orientation, providing ease of control and configuration of displays in any installation option. 55VH7J-H is equipped with webOS4.1 on SoC architecture and web platform, ensuring smooth multi-tasking. The developed graphical interface offers the user a convenient and intuitive tool for interacting with the functionality of LG webOS Signage displays. The built-in media player functionality allows the displays to independently display up to 4 web videos simultaneously with various animation effects, such as rotation or scaling, added using CSS effects. Streaming video is also supported, providing flexibility and variety in displaying content without the need to store it on the device's memory. Depending on the content, the user can set the optimal color temperature of the screen using the control panel, changing the values ​​in steps of 100K. Previously, video wall displays had a built-in “100% white” template for calibration, now the 55VH7J-H display has built-in gray background templates of varying brightness levels to obtain the best white balance calibration results. The 55VH7J-H is EMC ClassB certified. The certificate is required for electronic equipment used in residential premises and also commercial, industrial and office environments. As a result, video walls can be used in corporate conference rooms and meeting rooms. The LAN chain provides control, monitoring and updating of display firmware over a single cable. Combining video wall displays via a DP chain allows you to display UHD images on the video wall without the use of third-party video processors. Video walls can be installed in various locations. It is almost impossible to completely avoid negative environmental factors that reduce display performance. The special coating used for protection purposes on the printed circuit boards of the 55VH7J-H display can significantly reduce the risk of failure of the display, protecting it from salt, dust, metal shavings, high humidity, etc. IP5X (Dustproof) certification ensures that the product is protected from the harmful effects of fine particles and reduces the risk of reduced display performance due to mechanical contamination.

• Screen diagonal: 55"
• Technology: IPS
• Backlight type: Direct
• Aspect Ratio: 16:9
• Resolution: 1920 x 1080 (FHD)
• Frequency: 60Hz
• Brightness: 700 cd/m²
• Contrast: 1000:1
• Dynamic Contrast: 500.000:1
• Color gamut: NTSC 72%
• Viewing Angle (H x V): 178x178
• Color depth: 10bit, 1.07Billion colors
• Response Time: 8ms (G to G)
• Surface treatment (haze): 28%
• Lifespan: 60,000 hours (typ.) / 50,000 hours (min.)
• Operating hours: 24/7
• Portrait / Landscape: Yes / Yes
• Inputs: HDMI 2 (HDCP 2.2), DP (HDCP 2.2), DVI-D (HDCP 1.4), audio input, RS-232C input, RJ45 (LAN), IR input, USB 2.0 Type A
• Outputs: DP Out (Input: HDMI/DVI/DP), Audio Out, RS-232C Out, RJ45 (LAN)
• VESA: 600×400
• HW: Internal memory 8GB, sensor (temperature sensor, BLU sensor, acceleration sensor (gyroscope), local key)
• Security: CB/NRTL
• EMC: FCC Class "B" / CE / KC
• ErP: Yes (Energy Star 8.0 (EU only))
• OPS Type Compatible: Yes
• CMS SuperSign: Yes
• SuperSign WB: Yes
• LG Connected Care: Yes
• SuperSign Control / Control+: Yes / Yes
• SuperSign Media Editor: Yes
• OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek,Turkish, Arabic
• Basic: Remote Control (including 2 batteries), Power Cord, RS232C Cable, Network Cable, DP Cable, IR Receiver, Guide Bracket, Screws, Manual
• Option: OPS kit (KT-OPSF)
• IP Rating: IP5X tested
• Operating temperature: 0°C to 40°C
• Operating humidity: 10% of 80%
• Power supply type: Built-in
• Operating voltage: 100-240VAC
• Frequency: 50 / 60 Hz
• Normal mode: 210 W
• Maximum power consumption: 250 W
• BTU: 717 BTU/h (typ.), 853 BTU/h (max.)
• Smart Power Saving: 110W
• Off: 0.5 W
• DPM: 0.5 W
• Bezel Width: B2B: 1.74 mm (bezel to bezel), 1.3 mm (T/L), 0.44 mm (B/R) A2A: 2.49 mm (active area to active area), 1.75 mm (T/L), 0.74 mm (B/R)
• Frame Color: Black
• Monitor weight: 18.8 kg
• Monitor weight in packaging: 31.0 kg
• Display dimensions (W x H x D): 1212.2 x 683.0 x 86.9 mm
• Package size: 1353 x 855 x 263 mm
