Professional panel LG 49VL5G-A
LED panel LG 49VL5G-A is designed for building budget video walls with a thin seam of only 3.5 mm. Superior color accuracy and uniform brightness across the entire screen are ensured by precise calibration and innovative technologies incorporated into this panel. Connecting panels in a chain, thanks to the use of a pass-through port Display Port (DP) 1.2 or HDMI, eliminates the need for additional controllers, switches and splitters to create video walls in configurations up to 5x5 with 4K resolution, significantly reducing the cost of the video wall as a whole. Industrial and highly reliable components, thoughtful architecture allow this panel to be used around the clock for many years. Incredibly immersive experience with ultra-thin bezel The VL5G video wall display series delivers immersive viewing with an ultra-thin bezel with just a 3.5mm edge, and its outstanding IPS LCD panel displays clear images from any angle. With an extremely attractive and highly functional design, a video wall of these displays can be used to display advertisements and information anywhere. Flawless large video walls with ultra-thin bezels The almost invisible frame does not interfere with the perception of the image. The large screen that can be created from these panels is quite enough to attract the attention of passersby. Seam width compensation The VL5G series of video wall displays include an image enhancement algorithm that can reduce image shifts due to the presence of inter-panel seams. Objects located at the borders of the frame are adjusted to create the appearance of a continuous image with no visible seams. Increased viewing angle Large screens are usually located above the level of the human eye, so it is important for video walls to have the same image quality from any angle. The VL5G Series' viewing angle is wide enough to display vibrant colors across the entire screen without distortion, no matter where you view it. Easy color adjustment For video walls consisting of several displays, it is very important that the image on all screens is uniform in brightness and color tone. Depending on the content, the display color temperature can be easily adjusted in 100K increments using the remote control for each display individually. Easy white balance adjustment In conventional video walls, white balance can only be adjusted in full-white mode, but the VL5G allows you to change each gray scale value to provide more detailed and precise white balance adjustments.
- Diagonal: 49" (124.46 cm)
- Panel resolution: 1920 x 1080 pixels
- Matrix: IPS
- Aspect Ratio: 16:9
- Brightness: 500 cd/m2
- Contrast: 1000:1
- Viewing Angles (V/D): 178° / 178°
- Seam (panel to panel): 3.5 mm
- Pixel pitch: 0.56 x 0.56
- Response time: 8ms
- Number of colors: 1,073.0 million
- Factory color calibration: Yes
- Video inputs: 2 x HDMI 1 x DP 1 x DVI-D
- Video outputs: 1 x DP
- Audio inputs: Jack 3.5 mm
- Audio outputs: Jack 3.5 mm
- Control: RS232C RJ45 (LAN) IR
- Built-in video wall controller: Yes
- Video wall configuration: up to 15x15
- Video pass-through: up to UltraHD 4K 3840x2160 pixels
- Instrumented Color Calibration Support: No
- Management software: SuperSign CMS SuperSign Control/Control+
- Additional: HDCP1.4 screen rotation
- Operating mode: 24/7
- Working in portrait mode: Yes
- Operating temperature range: 0–40 °C
- Storage temperature range: -20 - 60°C
- Relative humidity: 10 – 80% (non-condensing)
- Power consumption in operating mode: 100 W
- Standby power consumption: <0.5 W
- Contents: Remote control (2 AAA batteries) Grounded power cable (Euro plug) RS-232C cable DP cable IR receiver Wall mounting template Screws User manual
- Manufacturer's warranty: 3 years
- VESA Mount: 600 x 400
- Dimensions without packaging (WxHxD): 107.76 x 60.78 x 8.97 cm
- Weight without packaging: 17.0 kg
- Packaged dimensions (WxHxD): 121.40 x 77.80 x 26.30 cm
- Package weight: 29.0 kg
