Professional panel Iiyama TF4237MSC-B2AG
Built on projected capacitive technology, the iiyama ProLite TF4237MSC-B2AG professional panel features external mounting brackets, making it an ideal solution for kiosk and retail integrators.
Price on request
- Diagonal: 42" 106.5cm
- Aspect Ratio: 16:9
- Panel: IPS Direct LED, AG anti-glare
- Resolution: Full HD 1080p, 1920 x 1080 (2.1 MP)
- Brightness: 400 cd/m? standard
- Brightness: 340 cd/m? with touch screen panel
- Contrast: 1000:1 standard
- Response time: 6ms
- Viewable area: horizontal/vertical: 178°/ 178°; right/left: 89°/ 89°; up;down: 89°/ 89°
- Number of colors: 16.7 million
- Touch technology: projected capacitive, multi-touch (12 touches - HID, if supported by OS), activated by touching fingers
- Number of touches: 12
- Glass thickness: 4 mm
- Glass hardness class: 7H minimum
- Light transmittance: 84%
- Viewable area: 522 x 927.9 mm; 20.6" x 36.5"
- Pixel Size (d x h): 0.4833 x 0.4833 mm
- Horizontal Frequency: 31.47 - 67.5 KHz
- Vertical scan frequency: 47 - 63 Hz
- Sync: Separate Sync
- Maximum (uninterrupted) working time: 24 hours/day
- Anti-glare coating: Yes
- External connector: RS 232C
- video input: VGA, DVI, HDMI
- Audio input: MiniJack
- Audio output: speakers
- Control: RS 232C, USB (touch), IR extender
- Plug & Play: VESA DDC2B™
- Controls: On-Screen Menu in 8 languages (EN, FR, ES, DE, NL, PL, RUS, IT) and 6 control buttons (Power, Scroll up/Volume+, Scroll down/Volume-, Auto/Exit, Input Select/OK, Menu)
- Controls: contrast, brightness, color settings, display settings (aspect ratio, gamma, sharpness, H. position, V. position, clock, phase, auto adjust) other settings (language, OSD time out, volume, mute, fan, anti image retention, opening logo, factory reset) schedule settings (date and time, timer day set, on timer input select, reset) input source, information
- Speakers: 2 x 7 W (stereo)
- Anti-theft protection: yes
- Regulations: CE, TUV-Bauart, CU, IPX1, 60950-1 ball drop test
- VESA standard: 400 x 200 mm
- Color: black
- External control: yes
- Orientation: landscape/portrait/face-up
- Metal bezel: yes
- Ball Drop test proof: yes
- Palm rejection: yes
- Driver: multi-touch: Windows® 7/8/8.1/10, Linux (3.0x) (for more details see manual p.16)
- Equipment: power cable, VGA signal cable, DVI-D signal cable, USB cable, IR-Extender cable, remote control, battery, clamper, quick start guide, safety guide
- Power supply: AC 100 - 240 V, 50 / 60 Hz
- Power supply: internal
- Power consumption: 66 W standard; max. 0.5 W (sleep mode)
- Power Management: VESA DPMS
- Dimensions W x H x D: 975.5 x 575 x 88 mm
- Weight: 24 kg
