Polariscope-Polarimeter PKS-250M
Polariscope-Polarimeter PKS-250M The device is designed to determine birefringence in flat workpieces and products made of transparent and lightly colored materials. Advantages and benefits: The device is used to quantify the magnitude of birefringence by the Sénarmont method, to evaluate the distribution of birefringence in an object by interference coloring, to study the distribution of birefringence in an object in circularly polarized light. A large viewing field allows you to control large-sized workpieces and parts, as well as simultaneous control of several samples. Manba: https://www.nv-lab.ru/catalog_info.php?ID=890
Price on request
- Parameter: Value
- Limit for measuring the path difference for birefringence with a quarter-wave phase plate, nm: ±540
- Light diameter, mm:
- - analyzer (size of the field being viewed);
- - matte screen: 250;
- 300
- Vernier division value: 1°
- Vernier reading value: 0.1°
- Limit of permissible basic error of the device when measuring the stroke difference with a Sénarmont compensator, nm: ±10
- Overall dimensions, mm: 566 × 561 × 1215
- Table height from floor, mm: 680
- Weight, kg, no more: 35
- Power consumption, VA, no more than: 550
- Power supply (voltage/frequency): 220±22 V
- 50 Hz
- Mean time between failures, hours, not less: 2500
- Established full service life, years, not less than: 5
