Optical microscope Biomed 4T LED
The Biomed 4T LED trinocular microscope is designed for examining microscopic specimens using the bright field method in transmitted light. If necessary, a slider for dark-field studies can be installed in the condenser (purchased separately). Such a device will take its rightful place in any medical or biological laboratory. The 100x objective allows for immersion studies. The achromatic lenses of the device have a large aperture and provide a clear image, minimizing possible distortions. The revolving device is designed to accommodate four lenses. The binocular part of the attachment has a convenient degree of inclination, and the eyepieces are equipped with enlarged front lenses, which ensures a high level of comfort for the user. You can also adjust the interpupillary distance, and using the diopter adjustment mechanism, compensate for the difference in vision between the eyes. The microscope is equipped with a 3 W LED backlight with adjustable brightness. The coarse and fine focusing knobs are located coaxially, and the sharpness adjustment increments are 0.001 mm. The delivery set includes 3 light filters, which are installed not in the condenser frame, but directly on the collector. The object table is equipped with a preparation guide and has control handles on the right side.
- Microscope type: biological
- Optical system: straight
- Microscope attachment: trinocular, 360° rotatable, 80%/20% light division
- Research method: bright field
- Purpose: educational/school
- Optics material: optical glass
- Microscope magnification, x: 40 - 1000
- Microscope head tilt angle: 30°
- Interpupillary distance, mm: 48 - 75
- Diopter adjustment: ±5 on the left tube
- Inner diameter of tubes: 23.2 mm
- Eyepieces: WF 10x
- Lenses: achromatic: 4x/0.13; 10x/0.3; 40x/0.7; 100x/1.25 oil
- Lens correction type: lenses are designed for tube length ∞ (infinity)
- Parfocal distance, mm: 45
- Turret: for 4 lenses
- Microscope stage: coordinate; drug manager; right-hand control handles, 155x135 mm
- Range of movement of the object table, mm: 50 - 75
- Condenser: centered Abbe condenser, max. numerical aperture 1.25
- Aperture: iris
- Focusing: coaxial arrangement of coarse and fine focusing knobs; division value 0.001 mm
- Backlight type: LED
- Brightness adjustment: yes
- Illumination location: bottom
- Light filters: yellow; blue, green, matte
- Case material: metal
- Weight, kg: 6.3
- Country of origin: Russia
- Package weight, kg: 8
- Package size, cm: 48 × 48 × 29
