Document scanner Plustek SmartOffice S60
The Plustek SmartOffice S60 scanner allows you to enter electronic text and images into your computer in a professional way. This is a flatbed scanner with a CIS contact sensor that contains a line of photocells. It moves under the glass as it scans, conveying information about the image line by line. The device uses LEDs as a light source, located on a moving platform next to the photo ruler. Plustek SmartOffice PL3060 works with A4 format, with a resolution of 600 dpi.
Price on request
- Image Sensor: CIS x 2
- Light source: LED
- Optical resolution: 600 dpi
- Hardware resolution: 600 x 600 dpi
- Scan modes: Color: 48-bit input; output 24-bit Grayscale: input 16-bit; Output 8-bit B&W: 1-bit
- Automatic Feeder Capacity (ADF): 1. 100 sheets (A4, 70g/㎡), maximum thickness up to 10mm. 2. 50 sheets (A3, 70g/㎡) 3. 20 sheets (business card) 4. Plastic card (Loading horizontal), maximum thickness up to 1.2mm, embossed cards can be scanned. Note: ADF capacity varies depending on paper weight.
- Working speed (ADF): 64 ppm / 128 ppm. (Color, 300 dpi, A4 horizontal) 64 ppm / 128 ipm. (Color, 200 dpi, A4 horizontal) 48 ppm / 96 ipm. (Color, 300 dpi, A4 book) 48 pages min/ 96 pages min. (Color, 200 dpi, A4 book) 36 pages min./ 72 pages min. (Color, 300 dpi, A3) 36 pages min./ 72 pages min. (Color, 200 dpi, A3) Note: Scan results may vary depending on software applications and computer power.
- Scan Area (Width x Length): Max: 304.8 x 431.8 mm (12” x 17”) Min: 50.8 x 63.5 mm (2” x 2.5”) Long Paper: 304.8 x 5080 mm (12” x 200”)
- Allowable weight (thickness) of paper: 40 by 220 g/m2
- Multi-feed detection: With ultrasonic sensor
- Daily load (sheets): 18,000
- Individual roller life (scanning): 300,000
- Pick roller life (scanning): 300,000
- Friction roller life (scanning): 100,000
- Control buttons: 5 buttons: Power, Up, Down, Cancel, Scan 9 function keys. All customizable.
- Power consumption: 24 Vdc/ 1.25 A
- Interface: USB 3.2 Gen 1x1
- Protocols: TWAIN compatible
- Acceptable Paper Size (Width x Length): Max: 304.8 x 431.8 mm (12” x 17”) Min: 13.2 x 13.2 mm (0.52” x 0.52”)
- OS support: Windows 7/8/10/11
- Hardware Requirements: 3.2 GHz CPU processor or higher [1] [1] For Windows, recommended: 3.2 GHz Intel® Core™ i7 processor with 4 CPU cores or higher. Minimum 4 GB RAM (recommended: 8 GB or more) 6 GB hard disk space for program installation Display size 1024x768 or larger.
- Software included: Plustek DocAction Plustek DocTWAIN
- Built-in OCR: Plustek OCR (Powered by ABBYY® FineReader®)
- Dimensions (Width x Depth x Height): 405 x 272 x 297 mm (15.95" x 10.7" x 11.69")
- Weight: 6.8 Kgs (14.99 Lbs)
